Maxhub Raptor 135" LED COB 1.5mm Pixel Pitch FHD

• Flip Chip COB technology, renowned for its exceptional resistance to scratches, impact, water, moisture, and static electricity.
• COB direct view LED display features a wider viewing angle and minimized moiré effect on the screen.
• Built-in high-performance processor, 8-core CPU + 4-core GPU + 6TOPs NPU
• 8GB RAM + 64GB ultra-large storage
• Side speaker with a 6-chamber, 6-driver speaker system
• Support wireless Screen Sharing Function
• WiFi 6, AP and STA modes, and WiFi 6 dual-band 2.4G/5G are available
• Support Bluetooth 5.3.
• Four HDMI input, enabling PBP, PIP, and POP video processing capabilities
• HDMI 2.0 output, realizing dual-screen display of different contents
• Expandable built-in PC, making easy integration of Windows system
• Built-in Android 13.0 system and Apps
• Support various scene modes for different application scenarios
• Built-in light sensors for intelligent space sensing, allowing for automatic brightness adjustment
• Overall standby power consumption≤0.5W
• Fully front access and hot swapping available
• Support adjustment modes via Wi-Fi, network cable and USB connection
• Built-in RS232(RJ45)interfaces can realize remote centralized control function
• All-in-one ultra-slim and lightweight design. 31mm Thickness and 3.8kg/Cabinet.
• Meet the RoHS directive requirements both in China and EU

Product Parameter

• Size: 135 inch
• Aspect Ratio: 16:9
• Resolution: 1920x1080mm
• Overall Size (LxH): 3030.8x1812.9mm
• Display Area (LxH): 3000x1687.5mm
• Screen Thickness: 31mm
• Net Weight: 110kg (wall-mounting bar and stand not included)
• Recommended Viewing Distance: ≥3.2m
• Maintenance Mode: Front Access
• Installation Mode: Stand, Wall-mounting

• Brightness: 100~600cd/㎡(Adjustable)
• Refresh Rate: 3840Hz
• Gray Scale: 13+6bit
• Contrast : 15000:1
• Colour Temperature: 2300~9300K(Adjustable)
• Viewing Angle Horizontal: 165°, Vertical 165°

• Operation Voltage: 100~240VAC 50/60Hz
• Standby Power: ≤0.5W
• Average Power Consumption of Overall Unit: 0.418KW
• Maximum Power Consumption of Overall Unit: 1.252KW

System Parameter

• Operating System Android: 13.0
• CPU: Four Cortex-A76+ four Cortex-A55, frequency 2.4GHz
• RAM: 8GB
• Storage: 64GB
• Media Format: Support mainstream video format such as MPEG-1,MPEG-2,MPEG-4,H.263,H.264,H.265,VC-1,VP9,V P8,MVC,AV1; Support audio formats such as MP3; Support JPG, JPEG, BMP, PNG, GIF and other image format.

Environmental Parameter

• Operation Temperature: -10℃~40℃
• Operation Humidity: 10%~80%RH No condensation
• Lifespan: 100,000 Hours

I/O Ports

• HDMI IN (HDMI2.0 *1，HDMI1.4 *3): 4 (2 internal, 2 external)
• HDMI OUT: 1(external)
• POE: 1(internal)
• USB 2.0: 1(internal)
• USB 3.0: 2(external)
• Type C: 1(external)
• 3.5 Audio Output: 2(1 internal, 1 external)
• 3.5 Audio Input: 1(external)
• RS232(RJ45): 1(internal)
• USB Out: 1(external)
• LAN: 2(internal)
